ISG Connect
- Control and monitor your heat pump via a web interface
- Compatible with all STIEBEL ELTRON hydronic heat pumps
- Viewable on a standard browser via an integral web interface or mobile device
- Communicates to the STIEBEL ELTRON customer service centre
- Option to control the system via a smartphone web app Various software extensions available: KNX, Modbus, Energy Management
- To be connected to the router of the home network
- Adjust temperature settings
- Temperature data logging
- Energy consumption (kWh) monitoring
- Fault reporting
Product Overview
This ISG Connect Internet Service Gateway connects the heat pump to the home network via LAN and enables the heat pump system to be operated using a browser. If the appliance data is also transmitted to the STIEBEL ELTRON Servicewelt (Internet Service Portal), the heat pump can be conveniently controlled from anywhere via the internet using the MyStiebel app. The ISG Connect is a required accessory for use of the SG Ready functions. The ISG can be integrated into an existing building management system via the Modbus TCP/IP data interface. ISG Connect enables control to an output specified by the power supply utility or energy manager (HEMS – Home Energy Management System) via relay contacts or EEBUS protocol.
Product Details
Technical Data
| Product Number | 206780 |
| Height | 82 mm |
| Width | 180 mm |
| Depth | 46 mm |
| CAN | RJ 45 |
| LAN | RJ 42 |
| SG Ready (Control Input) | RJ 10 |
| Application range, min. / max | 0–45°C |
